The whole set of equipment includes: X-ray fluorescence analysis host, computer, printer, grinder, tablet press, vacuum pump;
Advantages:
- The instrument is compact, simple and generous, can be used in vehicle and laboratory, the use method is simple, and the test efficiency is high;
- During the test, the design of upper illumination light path and vacuum test chamber can effectively eliminate the dust pollution to the detector in the field ring;
- The maximum design of the collimator makes the laser spot of the sample reach 150 mm, ensures the richness of the test signal and improves the test accuracy
- The closed directional air cooling ensures the stable working temperature of the X-ray tube and prolongs the service life of the X-ray tube;
- The sample analysis speed is fast, up to 60s, and 40 elements can be analyzed at the same time;
- The high damping movable foot shockproof design and the ultra stable vacuum sample control design ensure that the geometric relationship between each sample and the light tube and detector is consistent at
- all times, and shield the field vibration
- The impact caused by the accident;
- Large area and thick crystal detector, equipped with RH target X-ray tube and good heat dissipation, effectively ensure the test efficiency and stability;
- X-ray shielding design and polymer materials and safety linkage device effectively ensure no radiation leakage, so that testers can use safely;
